Instruction to connect smart devices to the amplifier through Bluetooth
- 1. Turn on Bluetooth on your phone
- 2. Press “Air-M” button on the front panel of the amp and wait for your phone to search.
- 3. Choose “F-3089” on your phone and connect it.
- 4. Now you are ready to stream music from your phone to the amp. Please note, Bluetooth will only send audio to the amp, graphic won’t get transferred.
Features:
- Professional Digital Echo with separate repeat and delay controls
- 3 Mic Inputs with individual volume controls and echo on/off switches
- Audio Bluetooth receiver built-in for streaming from smart devices
- Built-in MP3 Player Module
- Optical/ Coaxial Input
- 3 XLR Front 3- 1/4" Microphone Inputs
- 2 XLR Back 2-1/4" Microphone Inputs
- Musicmaster bass/mid/treble controls
- Mic Master bass/mid/treble/controls
- Mic with Individual bass/mid/treble controls
- Master Microphone Control
- Master Volume Control
- Source/Level output displays
- Subwoofer output
- 4 Sets of A/V/S-Video/Input/Output Jacks
- Digital Sound Effect
Amplifier:
Power Output (Peak) : 650W + 650W @ 8Ω
Power Output (RMS) : (250w+250W @ 4Ω) (150W+150W @ 8Ω)
Input Impedance: 47kΩ
Input Sensitivity: 150mV
Bass Control: +/- 15dB (100Hz)
Mid Control: +/- 15dB(1KHz)
Treble Control: +/- 1dB (10KHz)
T.H.D: <0.1%
Frequency Response: 20Hz-20KHz -1dB
Noise Ratio: >90dB
Power Source: 115V/60Hz
Product Dimension: 17(W) x 6 (H) x 12 (D) inches
Product Weight: 30 lbs
Microphone:
Connector: 1/4" TRS/Unbalanced
Input Impedance: 1.5KΩ
Input Sensitivity: 10mV
T.H.D.: <0.5%
Frequency Response: 20Hz - 15KHz -3dB
Noise Ratio: >85dB
Bass Control: +/- 15dB (100Hz)
Mid Control: +/- 12dB(1KHz)
Treble Control: +/- 15dB (10KHz)
Digital Echo: Up To 300ms
